R7F100GAG2DSP#AA0微控制器Renesas
發布時間：2024-07-15 09:26:59 瀏覽：231
R7F100GAG2DSP#AA0是Renesas公司推出的RL78/G23微控制器系列中的一員。這款微控制器以其超低功耗和豐富的功能而著稱，適用于多種應用場景。
主要特點：
1. 超低功耗：
工作電流為41μA/MHz，確保在運行時的高效能耗比。
在停止模式下，數據保留電流僅為210nA，適用于4KB的SRAM，這使得該微控制器在間歇操作時功耗極低。
2. 寬工作電壓范圍：
支持1.6V至5.5V的寬電壓范圍，適應多種電源環境。
最高工作頻率可達32MHz，滿足高速處理需求。
3. 大容量存儲：
內置高達768KB的代碼閃存和48KB的RAM，提供充足的存儲空間。
4. 多功能集成：
集成了電容式觸摸傳感單元(CTSU2L)，支持觸摸感應應用。
包含邏輯和事件鏈路控制器(ELCL)，增強系統的事件處理能力。
5. 靈活的封裝選項：
提供從30引腳到128引腳的多種封裝選項，滿足不同設計需求。
6. 豐富的開發環境：
提供快速原型開發板，支持用戶通過易于使用的GUI進行編程和調試。
只需連接USB電纜和智能配置器，無需額外工具，簡化開發流程。
7. 兼容性：
與現有的RL78系列兼容，可以無縫替代，方便升級和維護。
應用領域：
R7F100GAG2DSP#AA0微控制器適用于廣泛的領域，包括家用電器、消費電子產品和工業設備等，特別適合對功耗有嚴格要求的應用場景。
型號：
| Product ID | 程序存儲器 （KB） | 內存 （KB） | 溫度范圍 | 模數轉換器 | 數模轉換器 | 產品尺寸 （mm） |
| R7F100GAG2DSP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAG3CSP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ2DSP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ3CSP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GBG2DFP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG2DNP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBG3CFP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG3CNP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ2DFP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBJ3CFP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GEG2DNP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEG3CNP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GFG2DFP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFG3CFP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ2DFP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ3CFP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL2DFP#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL3CFP#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN2DFP#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN3CFP#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GGG2DFB#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG2DNP#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGG3CFB#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG3CNP#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ2DFB#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGJ3CFB#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL2DFB#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL3CFB#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN2DFB#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN3CFB#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GJG2DFA#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJG3CFA#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ2DFA#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ3CFA#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL2DFA#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL3CFA#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN2DFA#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN3CFA#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG2DFB#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG3CFB#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ2DFB#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ3CFB#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL2DFB#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL3CFB#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN2DFB#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN3CFB#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GMJ2DFB#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMJ3CFB#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML2DFB#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML3CFB#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN2DFB#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN3CFB#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GPL2DFB#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPL3CFB#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN3CFB#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GSL2DFB#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSL3CFB#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN2DFB#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN3CFB#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GAF2DSP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAF2DSP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAF2DSP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAF3CSP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAF3CSP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAF3CSP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAG2DSP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAG2DSP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAG3CSP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAG3CSP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH2DSP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH2DSP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH2DSP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH3CSP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH3CSP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAH3CSP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ2DSP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ2DSP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ3CSP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GAJ3CSP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 10 x 6 x 1.4 |
| R7F100GBF2DFP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF2DFP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF2DFP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF2DNP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBF2DNP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBF2DNP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBF3CFP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF3CFP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF3CFP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBF3CNP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBF3CNP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBF3CNP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBG2DFP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG2DFP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG2DNP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBG2DNP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBG3CFP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG3CFP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBG3CNP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBG3CNP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH2DFP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBH2DFP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBH2DFP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBH3CFP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBH3CFP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBH3CFP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBJ2DFP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBJ2DFP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBJ3CFP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GBJ3CFP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GEF2DNP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEF2DNP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEF2DNP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEF3CNP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEF3CNP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEF3CNP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEG2DNP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEG2DNP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEG3CNP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEG3CNP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GFF2DFP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFF2DFP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFF2DFP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFF3CFP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFF3CFP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFF3CFP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFG2DFP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFG2DFP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFG3CFP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFG3CFP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH2DFP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH2DFP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH2DFP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH3CFP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH3CFP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFH3CFP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ2DFP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ2DFP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ3CFP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFJ3CFP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK2DFP#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK2DFP#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK2DFP#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK3CFP#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK3CFP#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFK3CFP#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL2DFP#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL2DFP#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL3CFP#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFL3CFP#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN2DFP#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN2DFP#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN3CFP#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GFN3CFP#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 10 x 10 x 1.6 |
| R7F100GGF2DFB#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF2DFB#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF2DFB#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF2DNP#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGF2DNP#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGF2DNP#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGF3CFB#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF3CFB#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF3CFB#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGF3CNP#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGF3CNP#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGF3CNP#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGG2DFB#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG2DFB#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG2DNP#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGG2DNP#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGG3CFB#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG3CFB#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGG3CNP#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGG3CNP#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH2DFB#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGH2DFB#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGH2DFB#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGH3CFB#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGH3CFB#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGH3CFB#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGJ2DFB#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGJ2DFB#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGJ3CFB#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGJ3CFB#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK2DFB#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK2DFB#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK2DFB#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK3CFB#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK3CFB#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGK3CFB#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL2DFB#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL2DFB#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL3CFB#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGL3CFB#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN2DFB#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN2DFB#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN3CFB#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GGN3CFB#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 1.7 |
| R7F100GJF2DFA#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJF2DFA#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJF2DFA#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJF3CFA#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJF3CFA#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJF3CFA#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJG2DFA#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJG2DFA#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJG3CFA#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJG3CFA#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH2DFA#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH2DFA#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH2DFA#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH3CFA#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH3CFA#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJH3CFA#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ2DFA#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ2DFA#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ3CFA#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJJ3CFA#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK2DFA#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK2DFA#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK2DFA#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK3CFA#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK3CFA#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJK3CFA#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL2DFA#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL2DFA#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL3CFA#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJL3CFA#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN2DFA#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN2DFA#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN3CFA#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GJN3CFA#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF2DFA#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF2DFA#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF2DFA#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF2DFB#AA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF2DFB#BA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF2DFB#HA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF3CFA#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF3CFA#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF3CFA#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLF3CFB#AA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF3CFB#BA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLF3CFB#HA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG2DFA#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG2DFA#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG2DFA#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG2DFB#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG2DFB#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG3CFA#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG3CFA#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG3CFA#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLG3CFB#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLG3CFB#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH2DFA#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH2DFA#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH2DFA#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH2DFB#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH2DFB#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH2DFB#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH3CFA#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH3CFA#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH3CFA#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLH3CFB#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH3CFB#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLH3CFB#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ2DFA#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ2DFA#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ2DFA#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ2DFB#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ2DFB#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ3CFA#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ3CFA#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ3CFA#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLJ3CFB#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLJ3CFB#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK2DFA#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK2DFA#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK2DFA#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK2DFB#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK2DFB#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK2DFB#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK3CFA#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK3CFA#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK3CFA#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLK3CFB#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK3CFB#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLK3CFB#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL2DFA#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL2DFA#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL2DFA#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL2DFB#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL2DFB#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL3CFA#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL3CFA#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL3CFA#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLL3CFB#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLL3CFB#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN2DFA#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN2DFA#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN2DFA#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN2DFB#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN2DFB#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN3CFA#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN3CFA#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN3CFA#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 12 x 12 x 1.6 |
| R7F100GLN3CFB#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GLN3CFB#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 10 x 10 x 1.7 |
| R7F100GMG2DFA#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG2DFA#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG2DFA#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG2DFB#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMG2DFB#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMG2DFB#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMG3CFA#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG3CFA#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG3CFA#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMG3CFB#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMG3CFB#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMG3CFB#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH2DFA#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH2DFA#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH2DFA#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH2DFB#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH2DFB#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH2DFB#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH3CFA#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH3CFA#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH3CFA#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMH3CFB#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH3CFB#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMH3CFB#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMJ2DFA#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ2DFA#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ2DFA#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ2DFB#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMJ2DFB#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMJ3CFA#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ3CFA#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ3CFA#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMJ3CFB#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMJ3CFB#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK2DFA#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK2DFA#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK2DFA#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK2DFB#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK2DFB#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK2DFB#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK3CFA#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK3CFA#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK3CFA#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMK3CFB#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK3CFB#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMK3CFB#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML2DFA#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML2DFA#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML2DFA#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML2DFB#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML2DFB#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML3CFA#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML3CFA#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML3CFA#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GML3CFB#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GML3CFB#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN2DFA#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN2DFA#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN2DFA#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN2DFB#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN2DFB#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN3CFA#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN3CFA#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN3CFA#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GMN3CFB#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GMN3CFB#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch | 12 x 12 x 1.7 |
| R7F100GPG2DFA#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG2DFA#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG2DFA#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG2DFB#AA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPG2DFB#BA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPG2DFB#HA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPG3CFA#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG3CFA#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG3CFA#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPG3CFB#AA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPG3CFB#BA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPG3CFB#HA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH2DFA#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH2DFA#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH2DFA#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH2DFB#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH2DFB#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH2DFB#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH3CFA#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH3CFA#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH3CFA#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPH3CFB#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH3CFB#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPH3CFB#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ2DFA#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ2DFA#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ2DFA#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ2DFB#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ2DFB#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ2DFB#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ3CFA#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ3CFA#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ3CFA#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPJ3CFB#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ3CFB#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPJ3CFB#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK2DFA#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK2DFA#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK2DFA#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK2DFB#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK2DFB#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK2DFB#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK3CFA#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK3CFA#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK3CFA#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPK3CFB#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK3CFB#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPK3CFB#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPL2DFA#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL2DFA#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL2DFA#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL2DFB#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPL2DFB#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPL3CFA#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL3CFA#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL3CFA#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPL3CFB#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPL3CFB#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN2DFA#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN2DFA#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN2DFA#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN2DFB#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN2DFB#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN2DFB#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN3CFA#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN3CFA#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN3CFA#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GPN3CFB#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GPN3CFB#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch | 14 x 14 x 1.7 |
| R7F100GSJ2DFB#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSJ2DFB#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSJ2DFB#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSJ3CFB#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSJ3CFB#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSJ3CFB#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK2DFB#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK2DFB#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK2DFB#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK3CFB#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK3CFB#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSK3CFB#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSL2DFB#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSL2DFB#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSL3CFB#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSL3CFB#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN2DFB#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN2DFB#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN3CFB#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GSN3CFB#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 20 x 14 x 1.6 |
| R7F100GBH2DNP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH2DNP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH2DNP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH3CNP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH3CNP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBH3CNP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ2DNP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ2DNP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ2DNP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ3CNP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ3CNP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GBJ3CNP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 5 x 5 x 0.8 |
| R7F100GEH2DNP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEH2DNP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEH2DNP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEH3CNP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEH3CNP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEH3CNP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ2DNP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ2DNP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ2DNP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ3CNP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ3CNP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GEJ3CNP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch | 6 x 6 x 0.8 |
| R7F100GGH2DNP#AA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH2DNP#BA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH2DNP#HA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH3CNP#AA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH3CNP#BA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGH3CNP#HA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ2DNP#AA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ2DNP#BA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ2DNP#HA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ3CNP#AA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ3CNP#BA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGJ3CNP#HA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK2DNP#AA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK2DNP#BA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK2DNP#HA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK3CNP#AA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK3CNP#BA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGK3CNP#HA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL2DNP#AA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL2DNP#BA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL2DNP#HA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL3CNP#AA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL3CNP#BA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGL3CNP#HA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN2DNP#AA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN2DNP#BA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN2DNP#HA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN3CNP#AA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN3CNP#BA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GGN3CNP#HA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch | 7 x 7 x 0.8 |
| R7F100GCF2DLA#AC0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCF2DLA#BC0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCF2DLA#HC0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCF3CLA#AC0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCF3CLA#BC0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCF3CLA#HC0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG2DLA#BC0 | 128 | 16 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG2DLA#HC0 | 128 | 16 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG2DLA#AC0 | 128 | 16 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG3CLA#AC0 | 128 | 16 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG3CLA#BC0 | 128 | 16 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCG3CLA#HC0 | 128 | 16 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH2DLA#AC0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH2DLA#BC0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH2DLA#HC0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH3CLA#AC0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH3CLA#BC0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCH3CLA#HC0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ2DLA#AC0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ2DLA#BC0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ2DLA#HC0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ3CLA#HC0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ3CLA#AC0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GCJ3CLA#BC0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch | 4 x 4 x 0.76 |
| R7F100GLN2DLA#AC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN2DLA#BC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN2DLA#HC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN3CLA#AC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN3CLA#BC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN3CLA#HC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL2DLA#AC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL2DLA#BC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL2DLA#HC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL3CLA#AC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL3CLA#BC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLL3CLA#HC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK2DLA#AC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK2DLA#BC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK2DLA#HC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK3CLA#AC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK3CLA#BC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLK3CLA#HC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ2DLA#AC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ2DLA#BC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ2DLA#HC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ3CLA#AC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ3CLA#BC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLJ3CLA#HC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH2DLA#AC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH2DLA#BC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH2DLA#HC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH3CLA#AC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH3CLA#BC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLH3CLA#HC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG2DLA#AC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG2DLA#BC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG2DLA#HC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG3CLA#AC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG3CLA#BC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLG3CLA#HC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF2DLA#AC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF2DLA#BC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF2DLA#HC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF3CLA#AC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF3CLA#BC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLF3CLA#HC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch | 5 x 5 x 0.76 |
| R7F100GLN2DAA#AC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN2DAA#BC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN2DAA#HC0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN3CAA#AC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN3CAA#BC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN3CAA#HC0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL2DAA#AC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL2DAA#BC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL2DAA#HC0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL3CAA#AC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL3CAA#BC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL3CAA#HC0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK2DAA#AC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK2DAA#BC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK2DAA#HC0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK3CAA#AC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK3CAA#BC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK3CAA#HC0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ2DAA#AC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ2DAA#BC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ2DAA#HC0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ3CAA#AC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ3CAA#BC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ3CAA#HC0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH2DAA#AC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH2DAA#BC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH2DAA#HC0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH3CAA#AC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH3CAA#BC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH3CAA#HC0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG2DAA#AC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG2DAA#BC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG2DAA#HC0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG3CAA#AC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG3CAA#BC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG3CAA#HC0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF2DAA#AC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF2DAA#BC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF2DAA#HC0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF3CAA#AC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF3CAA#BC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF3CAA#HC0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG2DFB#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GBF3CFP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBG2DFP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GFF3CFP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFG2DFP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGF3CFB#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGG2DFB#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GJF3CFA#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJG2DFA#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF3CFB#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF3CFA#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG2DFA#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GMG3CFB#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMG2DFB#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMG3CFA#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMG2DFA#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GPG3CFB#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPG2DFB#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPG3CFA#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPG2DFA#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GBF2DFP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBG3CFP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GFF2DFP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFG3CFP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGF2DFB#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGG3CFB#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GJF2DFA#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJG3CFA#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF2DFB#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG3CFB#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLF2DFA#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLG3CFA#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GSN2DFB#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSL2DFB#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSK2DFB#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSJ2DFB#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSN3CFB#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSL3CFB#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSK3CFB#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GSJ3CFB#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GPL2DFB#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GMJ2DFB#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMH2DFB#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMJ3CFB#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMH3CFB#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GBG2DNP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAG2DSP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GPN2DFB#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GLN2DFB#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GGN2DFB#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GMJ2DFA#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GLJ2DFB#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJJ2DFA#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GGJ2DFB#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GBJ2DFP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GMN2DFA#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMN2DFB#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GJN2DFA#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GPN2DFA#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GLN2DFA#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GFN2DFP#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GBH2DFP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GGH2DFB#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGK2DFB#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGL2DFB#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GLK2DFA#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL2DFA#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH2DFB#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GMH2DFA#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GML2DFB#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GPH2DFA#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPJ2DFA#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPK2DFA#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPL2DFA#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GFN3CFP#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GAG3CSP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBJ3CFP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBH3CFP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBG3CNP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GGH3CFB#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGJ3CFB#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGN3CFB#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGL3CFB#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GJJ3CFA#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJN3CFA#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJK3CFA#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJL3CFA#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN3CFA#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK3CFA#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL3CFA#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ3CFB#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLN3CFB#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH3CFB#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK3CFB#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL3CFB#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GMJ3CFA#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMN3CFA#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMH3CFA#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMK3CFA#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GML3CFA#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMN3CFB#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMK3CFB#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GML3CFB#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GPN3CFA#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPH3CFA#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPJ3CFA#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPK3CFA#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPL3CFA#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPN3CFB#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPH3CFB#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPJ3CFB#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPK3CFB#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPL3CFB#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GAJ2DSP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAF2DSP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAH2DSP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAJ3CSP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAF3CSP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GAH3CSP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 8-ch | 8-bit x 2-ch |
|
| R7F100GBF2DNP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GBF3CNP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GBH2DNP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GBH3CNP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GBJ2DNP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GBJ3CNP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GEF2DNP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEF3CNP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEG2DNP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEG3CNP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEH2DNP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEH3CNP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEJ2DNP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GEJ3CNP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 9-ch | 8-bit x 2-ch |
|
| R7F100GFJ2DFP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFJ3CFP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGK3CFB#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGF2DNP#UA0 | 96 | 12 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGF3CNP#UA0 | 96 | 12 | -40 to 105°C | 12-bit x 26-ch | 8-bit x 2-ch |
|
| R7F100GGG2DNP#UA0 | 128 | 16 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGG3CNP#UA0 | 128 | 16 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGH2DNP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGH3CNP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGJ2DNP#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGJ3CNP#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGK2DNP#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGK3CNP#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGL2DNP#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGL3CNP#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGN2DNP#UA0 | 768 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GGN3CNP#UA0 | 768 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GJK2DFA#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJL2DFA#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH2DFA#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLH3CFA#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ2DFA#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLJ3CFA#UA0 | 256 | 24 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLK2DFB#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GLL2DFB#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GMK2DFA#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GML2DFA#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GMK2DFB#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 17-ch | 8-bit x 2-ch |
|
| R7F100GPH2DFB#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GPJ2DFB#UA0 | 256 | 24 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GFK3CFP#UA0 | 384 | 32 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFL2DFP#UA0 | 512 | 48 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFL3CFP#UA0 | 512 | 48 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GPK2DFB#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 20-ch | 8-bit x 2-ch |
|
| R7F100GFH2DFP#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFH3CFP#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GFK2DFP#UA0 | 384 | 32 | -40 to 85°C | 12-bit x 10-ch | 8-bit x 2-ch |
|
| R7F100GJH2DFA#UA0 | 192 | 20 | -40 to 85°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
| R7F100GJH3CFA#UA0 | 192 | 20 | -40 to 105°C | 12-bit x 12-ch | 8-bit x 2-ch |
|
